Sapphire Pulse AMD Radeon RX 6500 XT Graphics Card | 4GB GDDR6 Video Memory
4GB GDDR6 GPU Memory
1024 Stream Processors
Maximum 2 Displays Support
1 x HDMI, 1 x DisplayPort
PCI-Express 4.0 x 4 GPU Interface
Highlights: Sapphire Pulse AMD Radeon RX 6500 XT
GPU Memory Size 4GB GDDR6
GPU Memory Type GDDR6
GPU Interface PCI-Express 4.0 x 4
Stream Processors 1024
Maximum Display Support 2
About Sapphire Pulse AMD Radeon RX 6500 XT
The Sapphire Pulse AMD Radeon RX 6500 XT Graphics card runs on powerful Dual-X cooling technology with intelligent fan control to keep temperatures down and fan noise down. Refined PCB design provides stable, reliable, and stable performance, which efficiently reduces PCB temperature and component signal noise.
FEATURES:
Fuse Safety
To protect your card, fuse protection is built into the external PCI-E power connector circuit to protect SAPPHIRE card components.
Dual-X Cooling
SAPPHIRE۪s acclaimed Dual-X cooling is powered by two large but silent fans and a sophisticated radiator design. The new form of hybrid fan blades means more airflow and higher heatsink coverage with less noise than standard cooling designs.
Wise fan control
Fan speed is intelligently controlled to keep the GPU, memory, PWM IC, and other components at temperatures as low as possible to balance performance and fan noise.
Precise Fan Control
Standard industrial fans can vary up to 10% in the fan rotation cycle (RPM). Fan IC Control on SAPPHIRE graphics cards reduces the differential to about 3%. This ensures up to 70% accuracy improvement while ensuring the cooling and noise performance of each graphics card is up to scratch.
Engine Clock
Sapphire Pulse AMD Radeon RX 6500 XT features up to 2825 MHz Boost clock and 2685 MHz Game clock.
The boost clock is the maximum frequency that the GPU can achieve while running bursty workloads. Boost clock attainability, frequency, and stability will vary based on a variety of factors, including but not limited to thermal conditions and application and workload variations.
Game Clock is the expected GPU clock when running typical gaming applications, with a typical TGP(Total Graphics Power) set. Actual individual game clock results may vary.
TECHNICAL SPECIFICATIONS
GPU_ AMD Radeon RX 6500 XT
Chipset_ AMD
Architecture_ AMD RDNA 2 Architecture
Memory Size_ 4GB GDDR6
Memory Type_ GDDR6
Memory Clock_ 18 Gbps Effective
Stream Processors_ 1024
Vega_ 6nm GPU
Engine Clock_ Boost Clock: Up to 2825 MHz
Game Clock: Up to 2685 MHz
Infinity Cache_ 16MB
Ray Accelerators_ 16
Displays_ Maximum 2 Displays
Output_ 1 x HDMI, 1 x DisplayPort
Resolution_ HDMI: 7680 x 4320
DisplayPort1.4: 7680 x 4320
Interface_ PCI-Express 4.0 x 4
BIOS Support_ UEFI
Game Index_ 1080P
Sapphire Features_ Premium Digital Power Design
Fuse Protection
Dual-X Cooling Technology
Intelligent Fan Control
Precision Fan Control
Metal Backplate
TriXX Supported
TriXX Boost
AMD Features_ AMD RDNA 2 Gaming Architecture
DirectX 12 Ultimate support
AMD Smart Access Memory
AMD Infinity Cache
6nm GPU
PCI Express 4.0 support
AMD FreeSync Technology
DisplayPort 1.4 with DSC
HDMI support
Video Streaming up to 8K
AMD Radeon VR Ready Premium
AMD FidelityFX
AMD Radeon Image Sharpening
AMD Radeon Anti-Lag
AMD Radeon Software
Game Driver Optimizations
Cooling_ Dual Fans
Form Factor_ 2 slot, ATX
Power Consumption_ 130W (Board Power)
OS_ Linux, Windows 7*, Windows 10, and Windows 11 64-bit operating systems required
*Does not support all features including but not limited to Hardware Raytracing
System Requirement_ Minimum 400 Watt Power Supply
1 x 6-pin Power Connector.
PCI Express-based PC is required with one X16 lane graphics slot available on the motherboard.
Minimum 8GB of system memory. 16GB is recommended.
Dimension (L x W x H)_ 194 x 107 x 40 mm
Specification: Sapphire Pulse AMD Radeon RX 6500 XT Graphics Card | 4GB GDDR6 Video Memory
FANS_
2
Product Type_
Graphics Card
FORM FACTOR_
ATX , E-ATX , MICRO-ATX
Brand_
Sapphire
COLOR_
BLACK
CHIPSET_
AMD
PROCESSOR SERIES_
RX
CAPACITY_
4 GB
MEMORY TYPE_
GDDR6
LIGHTING_
NONE
WARRANTY_
2 Years Warranty
