Antec EDGE 750 750W 80 PLUS GOLD Power Supply SMPS

Product Name HCG750 Gold
Model Name HCG750 Gold
Type ATX 12V 2.4
Modular Fully Modular
Dimension (W x L x H) 140(L)*150(W)*86(H) mm
Warranty 10 years
Input Voltage 100-240 VAC å±10%
Input Current 10A-5A
Input Frequency Range 50Hz-60Hz
PFC Active PFC (>0.9 typical)
Power Good Signal 100-500ms
Efficiency 92% Typically
Protection OCP/OVP/UVP/SCP/OPP/OTP/SIP/NLO
Output Capacity 750W
Operation Temperature 0~40å¡C
Regulatory cTUVus/TUV/CB [IEC62368 Compliant] /RCM/CE/EAC/CCC/BSMI/FCC
Fan 120mm FDB Fan
Certifications 80 Plus Gold
Connector 1 x MB 24(20+4) Pin
2 x 8(4+4) Pin EPS 12V
4 x 8(6+2) Pin PCI-E
8 x SATA
3 x Molex
1 x FDD
Net Weight 2.11Kg
Gross Weight 3.42Kg
