Sapphire Rx 580 Pulse OC Radeon 8GB Graphics Card

Memory Size 8GB GDDR5

Interface PCI-Express 3.0

Memory Bus 256-bit

Resolution 5120 x 2880

Boost Clock 1366 MHz

Recommended reading:Sapphire NITRO+ AMD Radeon RX 6750 XT 12GB GDDR6 Graphic Card 11318-01-20G

TECHNICAL SPECIFICATIONS

Model_RX 580 8GB GDDR5 OC PULSE
GPU_RX 580, 14 nm FinFET
4th Graphics Core Next (GCN)
Engine Clock_Up to 1366 MHz, Boost
Stream Processors_2304
Memory Size/Bus_8GB GDDR5/256-bit
Memory Clock_8000 MHz effective
Displays_Maximum 5 Outputs
Interface_PCI-Express 3.0
Resolution_DisplayPort: 51202880@60Hz
HDMI: 40962160@60Hz
DVI:25601600@60Hz
Output_1x DVI-D
2x HDMI
2x DisplayPort 1.4
BIOS Support_UEFI
API_OpenGL 4.5
OpenCL 2.0
DirectX 12
Shader Model 5.0
Game Index_1440p gaming
Sapphire Features_Dual-X Cooling
Long Life Dual Ball Bearing Fans
Intelligent Fan Control III
Quick Connect System
Long Life Capacitor
Backplate
Black Diamond 4 Chokes
Fuse protection
AMD Features_Radeon VR Ready Premium
Radeon Software
Radeon FreeSync Technology
AMD LiquidVR Technology
4th Gen GCN Architecture
Radeon Chill
Radeon ReLive DirectX 12 Technology
AMD Eyefinity Technology (Gaming)
AMD App Acceleration
AMD CrossFire Technology
AMD CrossFire (Bridgeless)
3rd Gen 14nm Process Technology
OpenCL 2.0
OpenGL 4.5
AMD PowerTune Technology
TrueAudio Next
Unified Video Decoder (UVD)
Video Code Engine (VCE)
Virtual Super Resolution
The Vulkan API
Cooling_Dual-X Cooling Technology
Two ball bearing fan
Fan Quick Connect
Form Factor_2 Slots Occupied
Power Consumption_<225W OS_Windows 10, Windows 7, 64bit operating system required System Requirement_500 Watt or greater power supply (Recommended) 1 x 8-pin Power Connector PCI Express compliant motherboard with one x16 graphics slot Dimension_230X125X40 mm Weight (Approximate)_5 gm Specification: Sapphire Rx 580 Pulse OC Radeon 8GB Graphics Card Brand Sapphire CHIPSET AMD BIT RATE 256 CAPACITY 8 GB FANS 2 MEMORY TYPE GDDR5 PROCESSOR SERIES RX WARRANTY 3 Years Warranty Product Type Graphics Card FORM FACTOR ATX , E-ATX , MICRO-ATX
