Fractal Design Meshify C Mini Dark Window Black Tower Cabinet FD-CA-MESH-C-MINI-BKO-TGD

In stock

Meshify strikes an aggressive pose in the Fractal Design lineup with unparalleled cooling performance and a defiant new look. Like black diamond facets, the angular asymmetry of the Meshify C Mini Dark TG carves a space uniquely its own as a new force in high-airflow design.

Compare
SKU: IGO-20221010-1791 Category:

Meshify strikes an aggressive pose in the Fractal Design lineup with unparalleled cooling performance and a defiant new look. Like black diamond facets, the angular asymmetry of the Meshify C Mini Dark TG carves a space uniquely its own as a new force in high-airflow design.

Streamlined high-airflow design
Performance and capacity of a larger tower in a compact mATX designed tower
Angular mesh front panel maximizes air intake

Significantly smaller, but just as cool

Tempered glass with a distinctive tint completes the stealth-inspired black-on-black aesthetic with exceptional style.

The Meshify C Mini Dark TG has a remarkably compact footprint with the high-end component support of a larger tower, and with six fan mounts and multi-radiator liquid cooling capability, it has the cooling capacity to match. When performance is top priority and compromise is not an option, Meshify has you covered in style.

Streamlined high-airflow design

Angular mesh front panel maximizes air intake
Two preinstalled Fractal Design Dynamic X2 GP-12 120 mm fans deliver optimum airflow with minimal noise
Open interior layout creates an unobstructed airflow path from front intake to rear exhaust
Flexible storage options with room for up to five drives

Full interior visiblity

Tinted tempered glass side panel for a clean looking exterior with full interior visibility

Distinctive style

With stealthy black-on-black aesthetic

Easy-to-clean filters

Front, top and base with full PSU coverage and convenient front access

Open to suggestions

Sturdy steel drive trays with vibration-dampening rubber grommets cushion hard drives for smooth, quiet and reliable operation
Full length power supply shroud conceals drive cage and excess cabling for unrestricted airflow and a clean looking interior
Up to 35 mm of space behind motherboard plate with grommeted pass-throughs for clean cable routing

Room for flexibility

Conceal up to five storage devices with an adjustable and removable drive cage beneath the PSU shroud plus dedicated SSD mounts behind the motherboard tray.
Sturdy steel drive trays with vibration-dampening rubber grommets cushion hard drives for smooth, quiet and reliable operation
Flexible storage options with room for up to five drives
Up to 35 mm of space behind motherboard plate with grommeted pass-throughs for clean cable routing

Improved air cooling

Seven total fan positions allow for extensive air cooling. Two Fractal Design Dynamic X2 GP-12 fans come preinstalled for maximum airflow, minimal noise and 100,000 hour life expectancy.
Whatever your liquid cooling ambitions may be, Meshify C can make it happen with support for radiators up to 280 mm in the front and 240 mm up top.
Open interior layout creates an unobstructed airflow path from front intake to rear exhaust.
Even the largest enthusiast-class GPUs leave plenty of room for thick dual-fan rads in the front. The adjustable drive cage can be moved or removed to fit even the lengthiest heavy-duty PSUs.

Specification :

Product Code FD-CA-MESH-C-MINI-BKO-TGD
3.5‰Û_ or 2.5‰Û_ Drive capacity 2
Dedicated 2.5‰Û_ drive capacity 3
Expansion slots 5
Front ports 2x USB 3.0, Audio I/O, Power button, Reset button
Total fan mounts 7
Front fan 3x 120 mm or 2x 140 mm (1x Dynamic X2 GP-12 included)
Top fan 2x 120/140 mm
Rear fan 1x 120 mm (1x Dynamic X2 GP-12 included)
Bottom fan 1x 120 mm
Dust filters Bottom fan + PSU, Front fans, Top fans
Cable routing grommets Yes
Fixed velcro straps Yes
Captive thumbscrews Both side panels, SSD brackets
Left side panel Tempered glass panel
Right side panel Steel
Compatibility
Power supply type ATX
Motherboard compatibility mATX, ITX
Front radiator 120/240 mm, 140/280 mm (max width 144 mm)
Top radiator 120/240 mm (max component height on motherboard 40 mm)
Rear radiator 120 mm (max width 125 mm)
PSU max length 175 mm
GPU max length 315 mm with front fan mounted
CPU cooler max height 172mm
Cable routing space 15-35 mm
Dimensions
Case dimensions (LxWxH) 395 x 212 x 399 mm
Case dimensions w feet/protrusions/screws 409 x 217 x 412 mm
Net weight 6.28 kg
Package dimensions (LxWxH) 502 x 295 x 484 mm
Package weight 7.41 kg
Volume 33.4 Liters
Warranty 2 Years
